Grizzly G0601 - G0601 Wiring Diagram



READ ELECTRICAL SAFETY
ON PAGE 49!
A1
Ground
2T1 6T3
14NO
4T2
1L1 5L3
13NO
3L2
NHD C-18D
2T1 4T2 6T3
98 97
A2
96
O R
95
10
11
13
15
NTH-1 5
ON/OFF
Switch
A2
OL_NO AC
OUT
AC
IN
220V Motor
220V
Circuit Board
220V Magnetic Contactor
Switch and Overload Relay
Ground
Hot
Hot
Hot
DISCONNECT
SWITCH
(as recommended
)
3-PHASE
220 VAC
G0601 Wiring Diagram

Figure 81.






Figure 80.




