Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
2 PSS01M SET SCREW M6-1 X 10 55A P0640X055A UPPER WHEEL COVER ASSEMBLY
3 P0640X003 SPRING BUSHING 56 PB10M HEX BOLT M6-1 X 25
4 P0640X004 LIFTING EYE BOLT M10-1.5 57 PW03M FLAT WASHER 6MM
5 P0640X005 MACHINE BODY 58 P0640X058 WHEEL BRUSH
7 P0640X007 WHEEL SHAFT BUSHING 59 PCAP06M CAP SCREW M6-1 X 25
8 PW05M FLAT WASHER 4MM 60 P0640X060 DOOR KNOB
9 P0640X009 POWER CORD 14G 3W 61 PLN03M LOCK NUT M6-1
10 PN01M HEX NUT M6-1 62 P0640X062 STRAIN RELIEF 16MM
11 P0640X011 TENSION POINTER 63 P0640X063 HEIGHT POINTER
12 P0640X012 STEP SCREW M4-.7 X 6 64 PN03M HEX NUT M8-1.25
13 P0640X013 HINGE SHAFT 65 PB45M HEX BOLT M8-1.25 X 100
14 PRP91M ROLL PIN 5 X 35 66 P0640X066 KNOB BOLT M10-1.5 X 20
15 P0640X015 UPPER WHEEL SHAFT HINGE 67 P0640X067 KNOB BOLT M10-1.5 X 55
16 P0640X016 UPPER WHEEL SHAFT 68 P0640X068 LOCK HANDLE M10-1.5
17 P0640X017 WHEEL BUSHING 69 P0640X069 CAM
18 P6204-2RS BALL BEARING 6204-2RS 70 P0640X070 SHAFT BRACKET
19 P0640X019 UPPER WHEEL 17" 71 P0640X071 LEVER KNOB
20 PR25M INT RETAINING RING 47MM 72 P0640X072 LEVER ROD
21 PW01M FLAT WASHER 8MM 73 PN09M HEX NUT M12-1.75
22 PCAP11M CAP SCREW M8-1.25 X 16 74 P0640X074 QUICK-TENSION SHAFT
23 P0640X023 WOOD SAW BLADE 131-1/2" X 1/2" 75 PBHS22M BUTTON HD CAP SCR M8-1.25 X 20
24 PLW04M LOCK WASHER 8MM 76 PLW04M LOCK WASHER 8MM
25 PCAP14M CAP SCREW M8-1.25 X 20 77 P0640X077 PC BOARD POWER CORD
26 T23071 URETHANE TIRE 17" 1-PAIR 78 P0640X078 SHAFT COVER
27 P0640X027 LOWER WHEEL 17" 79 PSS09M SET SCREW M8-1.25 X 20
28 P0640X028 WHEEL PULLEY 80 PN03M HEX NUT M8-1.25
29 PN32 HEX NUT 1-14 81 P0640X081 LOWER WHEEL SHAFT
30 PLW09 LOCK WASHER 1" 82 P0640X082 MOTOR 2HP 220V 3-PH
31 P0640X031 MOTOR CORD 16G 4W 82-1 P0640X082-1 MOTOR FAN COVER
32 P0640X032 COMPRESSION SPRING 8 X 7-1/2 X 36 82-2 P0640X082-2 MOTOR FAN
33 PRP02M ROLL PIN 3 X 16 82-3 P0640X082-3 MOTOR JUNCTIONBOX
34 P0640X034 SPRING BASE PLATE 82-4 P6203ZZ BALL BEARING 6203ZZ
35 P51201 THRUST BEARING 51201 82-5 P6205ZZ BALL BEARING 6205ZZ
36 P0640X036 START/STOP SWITCH 220V CHENG SHANG 83 PB32M HEX BOLT M10-1.5 X 25
37 P0640X037 TENSION HANDWHEEL 84 PLW06M LOCK WASHER 10MM
38 P0640X038 TENSION ADJUSTING BOLT 85 P0640X085 MOTOR MOUNT
39 PFS07M FLANGE SCREW M5-.8 X 10 86 PBHS22M BUTTON HD CAP SCR M8-1.25 X 20
40 PTLW02M EXT TOOTH WASHER 5MM 87 P0640X087 STRAIN RELIEF PLATE
41 PN06M HEX NUT M5-.8 88 PFS07M FLANGE SCREW M5-.8 X 10
42 PFS08M FLANGE SCREW M5-.8 X 16 89 P0640X089 LOCK HANDLE BRACKET
43 P0640X043 CONTROL PANEL PLATE 90 PK15M KEY 5 X 5 X 35
44 PCAP11M CAP SCREW M8-1.25 X 16 91 PB18M HEX BOLT M8-1.25 X 20 LH
45 PW01M FLAT WASHER 8MM 92 P0640X092 MOTOR PULLEY
46 P0640X046 UPPER WHEEL SLIDING BRACKET 93 PVA44 V-BELT A44
47 PCAP06M CAP SCREW M6-1 X 25 94 PCAP04M CAP SCREW M6-1 X 10
48 PRIV006M STEEL BLIND RIVET 3 X 10MM 95 P0640X095 LOWER WHEEL COVER
49 PCAP04M CAP SCREW M6-1 X 10 95A P0640X095A LOWER WHEEL COVER ASSEMBLY
50 P0640X050 PLASTIC WINDOW 97 PW01M FLAT WASHER 8MM
51 P0640X051 VS DIAL 98 P0640X098 METAL SAW BLADE 131-1/2" X 1/2"
52 P0640X052 VS POTENTIOMETER CF-X2-M-SA6M46E JIA XIN 99 PS12M PHLP HD SCR M3-.5 X 6
53 P0640X053 ON/OFF KEY SWITCH PLATE 100 PN07M HEX NUT M3-.5
54 P0640X054 KEY SWITCH 22 JUN YANG 101 P0640X101 DIGITAL DISPLAY
55 P0640X055 UPPER WHEEL COVER 102 P0640X102 KEY SWITCH CONNECTOR CORD 14G
