02'(/*+30,//'5,//
EgdYjXi9^bZch^dch/
Weight.............................................................................................................................................................. 566 lbs.
Width (side-to-side) x Depth (front-to-back) x Height..................................................................... 50 x 40 x 48-1/2 in.
Footprint (Length x Width)............................................................................................................................ 24 x 16 in.
H]^ee^c\9^bZch^dch/
Type.......................................................................................................................................................... Wood Crate
Content........................................................................................................................................................... Machine
Weight.............................................................................................................................................................. 674 lbs.
Length x Width x Height....................................................................................................................... 38 x 30 x 46 in.
:aZXig^XVa/
Minimum Circuit Size............................................................................................ 20 amps at 110V, 15 amps at 220V
Switch................................................................................................. Push Button with Thermal Overload Protection
Switch Voltage..................................................................................................................................................... 110V
Cord Length............................................................................................................................................................ 6 ft.
Cord Gauge................................................................................................................................................... 14 gauge
Plug Included.......................................................................................................................................................... Yes
Bdidgh/
BV^c
Type.................................................................................................................. TEFC Capacitor Start Induction
Horsepower................................................................................................................................................ 2 HP
Voltage................................................................................................................................................ 110/220V
Prewired..................................................................................................................................................... 110V
Phase....................................................................................................................................................... Single
Amps......................................................................................................................................................... 16/8A
Speed................................................................................................................................................ 1725 RPM
Cycle......................................................................................................................................................... 60 Hz
Number of Speeds............................................................................................................................................ 1
Power Transfer .................................................................................................................................. Belt Drive
Bearings....................................................................................................... Shielded, Permanently Lubricated
BV^cHeZX^[^XVi^dch/
DeZgVi^dc>c[d
Spindle Travel.............................................................................................................................................. 5 in.
Swing................................................................................................................................................... 15-7/8 in.
Longitudinal Table Travel.................................................................................................................... 23-1/2 in.
Cross Table Travel...................................................................................................................................... 7 in.
Ram Travel................................................................................................................................................ 12 in.
Head Travel........................................................................................................................................... 5-1/4 in.
Head Tilt (Left-to-Right)........................................................................................................................ 360 deg.
Maximum Distance Spindle to Column........................................................................................................ 8 in.
Maximum Distance Spindle to Table......................................................................................................... 18 in.
Drilling Capacity for Cast Iron................................................................................................................ 1-1/4 in.
Drilling Capacity for Steel...................................................................................................................... 1-1/4 in.
Number of Vertical Spindle Speeds................................................................................................................ 12
Range of Vertical Spindle Speeds..... 150, 225, 255, 350, 400, 500, 850, 1200, 1500, 1600, 2300, 3000 RPM
Quill Diameter....................................................................................................................................... 2.950 in.

Grizzly G1006 Specifications

General

Brand	Grizzly
Model	G1006
Category	Drill
Language	English
