Grizzly G1013 User Manual

-8- G1013 Combination Sander
Parts Inventory
After all the parts have been removed from the
carton, you should have:
• Belt Guard
• Disc Guard
• Disc Table
• Bolt Bag
• Table Support
• Sanding Unit
• Motor
• Miter Gauge
• Belt Table
• V-Belt
• Base
• Aluminum Disc
• Disc Sanding Paper
• Motor Pulley
NOTICE
A full parts list and breakdown drawing can
be found toward the end of this manual. For
easier assembly, or to identify missing
parts, please refer to the detailed illustra-
tions at the end of the manual.
Hardware Qty
5
⁄16" - 18 x
5
⁄8" Carriage Bolts 5
5
⁄16" - 18 x
3
⁄4" Hex Bolts 4
5
⁄16" - 18 Hex Nuts 13
5
⁄16" Flat Washers 20
1
⁄4" - 20 x 1
1
⁄4" Hex Bolts 4
1
⁄4" - 20 x 1" Hex Bolts 4
1
⁄4" - 20 Nuts 4
1
⁄4" Flat Washers 16
1
⁄4" - 20 x 1
1
⁄4" Carriage Bolts 2
1
⁄4" - 20 Wing Nuts 2
M5-0.8 x 6mm Phillips
®
Head Screws 4
5mm Flat Washers 4
1
⁄4" - 20 x
3
⁄8" Setscrews 2
3
⁄16" Sq. x
3
⁄4" Keys 2
5
⁄16" Fender Washer 1
Rubber Feet 4
Wire Nuts 2
3mm Allen
®
Wrench 1
