Grizzly G1021 User Manual

G1021 15" Planer -43-
Ref# Part# Description
116B PK06M KEY 5 x 5 x 10mm
117 P1021117 GEAR AND SHAFT
119 P1021119 GEAR, 2 SPEED
120 P1021120 GEAR
121 P1021121 DOUBLE GEAR
122 P1021122 SHAFT
123 PK11M KEY 6 x 6 x 40mm
124 PK21M KEY 5 x 5 x 23mm
125 P1021125 OIL SEAL 25 x 47 x 7mm
127 P1021127 SPRING
128 P1021128 BALL 6mm
129 P1021129 SHIFTER
131 P1021131 SHIFTING HANDLE
132 P1021132 O-RING 12mm
133 P1021133 GEAR CASE
134 P1021134 KNOB
135 PSB06M CAP SCREW M6 - 1.0 x 25mm
136 P1021136 PIN
137 P1021137 SPROCKET
138 P1021138 SPECIAL WASHER
139 PB18M HEX BOLT M6 - 1.0 x 25mm
140 P1021140 CHAIN, 23 LINKS
141 P1021141 CHAIN COVER
142 PSB05M CAP SCREW M8 - 1.25 x 50mm
143 P1021143 THREADED GIB
144 P1021144 LOCKING ROD
145 P1021145 LOCKING KNOB
146 P1021146 GIB
147 PSB01M CAP SCREW M6 - 1.0 x 16mm
148 PW03M FLAT WASHER 6mm
149 P1021149 SPROCKET
150 PK21M KEY 5 x 5 x 23mm
151 P1021151 OUTFEED ROLLER
152 P1021152 SPRING
153 P1021153 BUSHING BLOCK
154 P1021154 CHIPBREAKER
155 PN01M HEX NUT M6 - 1.0
156 PSS11M SET SCREW M6 - 1.0 x 16mm
Ref# Part# Description
157 P1021157 CHIPBREAKER ADJUST ROD
159 PR05M E-CLIP 15mm
160 P1021160 SPACER
161 P1021161 ANTI-KICKBACK FINGER
162 P1021162 SHAFT
163 P1021163 INFEED ROLLER
164 P1021164 SPROCKET
165A P1021165A CHAIN, 31 LINKS
166 P1021166 KNIFE GAUGE
167 PWR810 WRENCH, 8 x 10mm
167A PWR1214 WRENCH, 12 x 14mm
168 P1021168 CHIP CHUTE
169 G1197 COMPLETE STAND
170 G1196 KNIFE, SET OF 3
172 PHL01 REPLACEMENT HALF LINK
173 PML01 REPLACEMENT MASTER LINK
174 P1021174 DEPTH LIMITER
175 PFH05M FLAT HD SCRW M5 - 0.8 x 12mm
176 P1033097 RETAINER
177 PR03M SNAP RING 12mm
178 P1021178 PIVOT ROD
179 PN09M HEX NUT M12 - 1.75
180 P1021180 STRAIN RELIEF
181 PSW01-1 SWITCH COVER SCREW
182 PLW03M LOCK WASHER 6mm
183 PWRCRD220L POWER CORD 220V, LONG
184 PWRCRD220S POWER CORD 220V, SHORT
185 PK15M KEY 5 x 5 x 35mm
186 PAW03M ALLEN
®
WRENCH 3mm
187 PAW04M ALLEN
®
WRENCH 4mm
188 PAW05M ALLEN
®
WRENCH 5mm
189 PAW06M ALLEN
®
WRENCH 6mm
191 PSB04M CAP SCREW M6 - 1.0 x 10mm
192 P1021192 LABEL
193 P1033105 SPACER
194 P1033104 SPRING
195 P1033102 SHAFT
196 P1033103 HANGER

Grizzly G1021 Specifications

General

Model	G1021
Type	Planer
Number of Knives	3
Maximum Cutting Width	15 inches
Maximum Cutting Depth	1/8 inch
Dust Port Size	4 inches
Feed Rate	20 FPM
Feed Speed	20 FPM
