Figure 1. Recommended 220V receptacle.
-4- G1037 Planer / Moulder
110V Operation
The motor supplied with the G1037 is a dual volt-
age motor, prewired for 110V. Under normal use,
the motor draws approximately 17 amps @ 110V,
8.5 @ 220V. We recommend using a 20 amp cir-
cuit breaker or a 30 amp slow blow fuse for 110V
or 220V operation. This should be satisfactory for
normal use, while preventing motor damage from
high heat caused by overload. If frequent circuit
failures occur when using the planer/moulder,
contact our service department or your local elec-
trical contractor.
220V Operation
An instruction sheet has been included for
rewiring for 220V. If this sheet is missing, call the
appropriate service center for more information.
Do not attempt to rewire without the instruction
sheet.
SECTION 2: CIRCUIT REQUIREMENTS
