Grizzly G1183 - 220 V Wiring Diagram



READ ELECTRICAL SAFETY
ON PAGE 37!
220V Wiring Diagram
Motor
(viewed from bottom)
B1 B2 B3
A1 A2 A3
B1
A1
B2
A2
B3
A3
Ground
ON/OFF
Switch
220VAC NEMA 6-15
(As Recommended)
Start Capactitor
200M 250V
Run Capactitor
25M 350V
Hot
Hot
Ground
G
