Grizzly G4002 User Manual

-12-
Model G4003 (Mfd. Since 6/20)
Power Connection
Before the machine can be connected to the
power source, an electrical circuit, power cord,
plug, and receptacle must be prepared according
to the specifications and instructions in POWER
SUPPLY on Page 10.
Before connecting the machine to power,
always make sure the reset button on
the control panel is pushed in to avoid
unexpected start-ups.
Connecting Power Cord
1. Make sure the power cord is NOT connected
to power.
2.
Open the electrical cabinet and identify the
L and N terminals, and the grounding plate
(PE) at the bottom left of the cabinet (see
Figure 2).
3.
Attach insulated crimp-on wire terminals to
the wires of the power cord.
4.
Securely connect the incoming ground to the
PE terminal and the two incoming hot leads
to the L and N terminals.
5.
Close and secure the electrical cabinet.
A1
A2
A2
1L1
3L2
5L3
21NC
2T1
4T2
6T3
22NC
KM1
Contactor
Tianshui
GSC1-1801 110V
A1
A2
A2
1L1
3L2
5L3
21NC
2T1
Ground
To Motor
To Control
Panel
To Spindle
Switches
4T2
6T3
22NC
KM2
Contactor
Tianshui
GSC1-1801 110V
A1
A2
A2
13NO
23NO
33NO
43NO
14NO
24NO
34NO
44NO
KA0
Contactor
Tianshui
JZC3-40D 110V
FR1
OL Relay Tianshui JRS4-09 - 25D
13
11
9
25
400V
380V
240V
24
23
22
21
20
E
31
30
Transformer
Tianshui
JBK5-63VATH
L
N
L
N
L
N
L N
0
1
PE
1
0
0
0
0
TC
1L1
2T1
4T2
6T3
98NO 97NO 95NC 96NC
3L2
5L3
L
L
L
N
N
L
L
8
8
2
2
2
3
3
5
U1
PE
U1
9
9
10
10
U2
Z1
Z2
U2
Z1
Z2
U2
Z1
Z2
1
1
6
6
7
7
2 Amp
Fuse
PE
PE
U2
U1
Z1
Z2
1
0
2
3
5
7
6
4
PE
Lb
230V
220V
220V
110V
110V
5
PE
To Power
Source
Figure 2. Incoming power cord connections.
Hot
Ground
Connecting Power
Figure 3. Connecting power.
1. TurnthemachinepowerswitchOFF.
2.
 Insert the power cord plug into a
matching
power supply receptacle. The machine
is
nowconnectedtothepowersource.
Disconnecting Power
Figure 4. Disconnecting power.
1. TurnthemachinepowerswitchOFF.
2.
 Graspthemoldedplugandpullit
completely
outofthereceptacle.Donotpullbythe
cord
asthismaydamagethewiresinside.
