Grizzly G4003 User Manual

Model G4003 (Mfd. Since 6/20)
-49-
BUY PARTS ONLINE AT GRIZZLY.COM!
Scan QR code to visit our Parts Store.
REF PART # DESCRIPTION REF PART # DESCRIPTION
501 P4003501 SADDLE 522 P4003522 SLIDE PLATE
502 P4003502 PHLP HD SCR M3-.5 X 14 523 P4003523 SLIDE PLATE
503 P4003503 WIPER 524V2 P4003524V2 SLIDE PLATE 3 HOLES V2.01.09
504 P4003504 PHLP HD SCR 8-32 X 3/8 525 P4003525 HEX BOLT M8-1.25 X 24
505 P4003505 COVER 526 P4003526 WIPER
506 P4003506 CAP SCREW M5-.8 X 14 528 P4003528 HANDLE
507 P4003507 WIPER 529A P4003529A BRACKET
508 P4003508 ROLL PIN 5 X 45 530A P4003530A SET SCREW
509 P4003509 CAP SCREW M8-1.25 X 35 531A P4003531A SPANNER NUT
510 P4003510 SCREW 533 P4003533 SIGN BOARD
511 P4003511 SCREW 534 P4003534 RIVET 2 X 3MM STEEL
512 P4003512 CROSS SLIDE 535 P4003535 THRUST BEARING 51102
513 P4003513 GIB 536 P4003536 BRACKET
514 P4003514 BUSHI NG 537 P4003537 CAP SCREW M6-1 X 25
515 P4003515 CROSS SLIDE NUT M8-1.25, BRASS 539 P4003539 CROSS SLIDE LEADSCREW
518 P4003518 SLIDE PLATE 540 P4003540 GEAR 13T
519 P4003519 CAP SCREW M8-1.25 X 25 541 P4003541 CAP SCREW M6-1 X 8
520 P4003520 WIPER 542 P4003542 DI AL
521 P4003521 SCREW
Saddle Parts List
