Grizzly G4016 Parts List

-66-
G4016 13½" x 40" Gear Head Lathe
REF PART # DESCRIPTION REF PART # DESCRIPTION
301 P4016301 GEARBOX CASTING 351 P4016351 KNOB
302 P4016302 LOCK COLLAR 352 P4016352 CHANGE GEAR 30T
303 P4016303 COLLAR 356 P4016356 STUD M10-1.5 X 60
304 P4016304 COVER 358 PW04M FLAT WASHER 10MM
305 P4016305 BEARING CAP 359 P4016359 COLLAR
306 P4016306 BRACKET 360 P4016360 PLATE W/FEED CHART
307 P4016307 LEVER ARM 362 P4016362 COVER SLEEVE
308 P4016308 GEARBOX COVER 363 P4016363 COLLAR
309 P4016309 HANDLE BODY 364 P4016364 BUSHING
310 P4016310 HANDLE BODY 365 P4016365 SLIP FITTING
311 P4016311 LEVER SHAFT 366 P4016366 COLLAR
312 P4016312 GEAR 28T 367 P4016367 COLLAR
313 P4016313 GEAR 26T 369 P4016369 TAPER PIN 3 X 32
314 P4016314 GEAR 370 P4016370 KNOB M10-1.5
315 P4016315 GEAR 23T 373 P4016373 COVER
316 P4016316 GEAR 22T 375 P4016375 PLUG
317 P4016317 GEAR 20T 376 PB04M HEX BOLT M6-1 X 10
318 P4016318 GEAR 18T 377 PN02M HEX NUT M10-1.5
319 P4016319 GEAR 16T 378 PN02M HEX NUT M10-1.5
320 P4016320 GEAR 16T 379 PN01M HEX NUT M6-1
321 P4016321 GEAR 32/16T 380 PSB02M CAP SCREW M6-1 X 20
322 P4016322 COVER 381 PSB01M CAP SCREW M6-1 x 16
323 P4016323 GEAR 16T 382 PSB40M CAP SCREW M8-1.25 X 35
324 P4016324 SHAFT 384 PSS07M SET SCREW M5-.8 X 5
325 P4016325 SHAFT 385 PSS31M SET SCREW M5-.8 X 8
326 P4016326 GEAR 32/16T 386 PFH05M FLAT HD SCR M5-.8 X 12
327 P4016327 COVER 387 PW01M FLAT WASHER 8MM
328 P4016328 GEAR 82/16T 388 PW04M FLAT WASHER 10MM
329 P4016329 SHAFT 389 PRP52M ROLL PIN 6 X 16
330 P4016330 SHAFT 391 PRP70M ROLL PIN 5 X 18
331 P4016331 GEAR 40T 392 PRP27M ROLL PIN 5 X 28
332 P4016332 BEARING BRIDGE 393 PRP45M ROLL PIN 5 X 32
333 P4016333 COLLAR 394 PRP28M ROLL PIN 5 X 40
334 P4016334 GEAR 40T 396 PR23M INT RETAINING RING 40MM
335 P4016335 COLLAR 397 P4016397 EXT RETAINING RING 55MM
336 P4016336 SHAFT COVER 399 PK05M KEY 4 X 4 X 10
337 P4016337 COLLAR 400 PK47M KEY 4 X 4 X 15
338 P4016338 SPECIAL SCREW 401 PK68M KEY 4 X 4 X 40
339 P4016339 COLLAR 402 PK18M KEY 4 x 4 x 82
340 P4016340 GEAR 120T 403 PK20M KEY 5 X 5 X 15
341 P4016341 GEAR 127T 404 PK07M KEY 6 x 6 x 20
342 P4016342 LEVER 405 P8103 THRUST BEARING 8103
343 P4016343 GEAR 24T 406 P4016406 BEARING 2G80102 15 x 32 x 9
344 P4016344 SHAFT 407 P6003 BALL BEARING 6003ZZ
345 P4016345 GEAR 24T 408 P6203A BALL BEARING P6203Z
346 P4016346 SHAFT 409 P4016409 SPRING 0.8 X 4.5 X 70
347 P4016347 GEAR 32T 410 P4016410 SPRING 1 x 1.9 x 70
348 P4016348 SHAFT 411 P4016129 STEEL BALL 5MM
349 P4016349 SHAFT 412 P4016412 OILER 6MM
350 P4016350 THREADED PIN 413 PSS05M SET SCREW M5-.8 X 10
