G4016 13½" x 40" Gear Head Lathe

-61-

REF PART # DESCRIPTION REF PART # DESCRIPTION

150 P4016150 MOTOR MOUNT 240 P4016240 PLUG

203 P4016203 BED 241 P4016241 PLUG

204 P4016204 GAP 242 P4016242 PLUG

206 P4016206 BRACKET 243 P4016243 THREADED SHAFT

207 P4016207 BRACKET 244 P4016244 COVER

209 P4016209 COLLAR 245 P4016245 LOCK KNOB M8-1.25

210 P4016210 HANDLE BODY 246 PSS31M SET SCREW M5-.8 X 8

211 P4016211 RACK 247 PSS06M SET SCREW M8-1.25 X 16

213 P4016213 RACK 249 PSB47M CAP SCREW M10-1.5 X 40

216 P4016216 LEAD SCREW 251 PSB02M CAP SCREW M6-1 X 20

219 P4016219 FEED ROD 252 PSB60M CAP SCREW M8-1.25 X 55

222 P4016222 SHAFT 253 PN03M HEX NUT M8-1.25

223 P4016223 COLLAR 254 PSS19M SET SCREW M8-1.25 X 30

224 P4016224 THREADED SHAFT 255 PB38M HEX BOLT M12-1.75 X 60

225 P4016225 HANDLE 259 P4016259 ROUND PIN 6 X 25

226 P4016226 BRAKE RING 261 PRP46M ROLL PIN 6 X 28

227 P4016227 COLLAR 262 PRP34M ROLL PIN 6 X 55

228 P4016228 KEY 4 X 35 267 P4016267 SPRING 1 X 7.5 X 25

239 P4016239 KNOB M10-1.5 268 P4016268 OIL PORT 8MM
