Grizzly G4016 Parts List

-70-
G4016 13½" x 40" Gear Head Lathe
REF PART # DESCRIPTION REF PART # DESCRIPTION
501 P4016501 APRON CASTING 553 P4016553 KNOB M8-1.25
502 P4016502 HANDWHEEL 554 P4016554 PLUG "A"
503 P4016503 BOX 555 P4016555 PLUG "B"
504 P4016504 COVER 556 P4016556 HANDLE
505 P4016505 THREADING DIAL BODY 557 P4016557 COMPRESSION SPRING
506 P4016506 SPACER 558 P4016558 COMPRESSION SPRING
507 P4016507 GIB 559 PK15M KEY 5 X 5 X 35
508 P4016508 HANDLE BODY 560 PSB33M CAP SCREW M5-.8 X 12
509 P9036509 HANDLE 561 P4016561 HUB
510 P4016510 INDEX RING 562 PSB26M CAP SCREW M6-1 X 12
511 P4016511 COVER 563 PSB01M CAP SCREW M6-1 x 16
512 P4016512 SHAFT 564 PSB06M CAP SCREW M6-1 X 25
513 P4016513 GEAR PIN 60T 565 PSB13M CAP SCREW M8-1.25 X 30
514 P4016514 GEAR SHAFT 18T 566 PSB05M CAP SCREW M8-1.25 X 50
515 P4016515 GEAR 60T 567 PSB24M CAP SCREW M5-.8 X 16
516 P4016516 SHAFT 568 PSB26M CAP SCREW M6-1 X 12
517 P4016517 COVER 569 PSB04M CAP SCREW M6-1 X 10
518 P4016518 GEAR 30T 570 PSS26M SET SCREW M5-.8 X 6
519 P4016519 GEAR 46T 571 PSS02M SET SCREW M6-1 X 6
522 P4016522 GEAR 63T 572 PSS01M SET SCREW M6-1 X 10
523 P4016523 SHIFT FORK 573 PSS34M SET SCREW M5-.8 X 16
524 P4016524 SHIFT LEVER 574 PSS29M SET SCREW M6-1 X 35
525 P4016525 SHIFT HANDLE 575 PSS01M SET SCREW M6-1 X 10
526 P4016526 GEAR 40T 576 P4016576 BRACKET
528 P4016528 BRACKET 577 PSB26M CAP SCREW M6-1 X 12
529 P4016529 HALF NUT 578 PRP16M ROLL PIN 3 X 25
530 P4016530 WORM 579 PRP03M ROLL PIN 5 X 20
531 P4016531 GEAR 22T 580 PRP05M ROLL PIN 5 X 30
532 P4016532 SHAFT 581 PRP45M ROLL PIN 5 X 32
533 P4016533 GEAR 18T 582 PRP49M ROLL PIN 5 X 25
534 P4016534 SHAFT 583 PRP83M ROLL PIN 8 X 12
535 P4016535 THREADING DIAL SHAFT 584 P4016584 OILER 8MM
538 P4016538 GEAR 32T 586 PLW04M LOCK WASHER 8MM
539 P4016539 SPACER 587 PN06M HEX NUT M5-.8
540 P4016540 BAR 588 PN01M HEX NUT M6-1
541 P4016541 SPECIAL BOLT M8-1.25 X 13 589 PN03M HEX NUT M8-1.25
542 PW03M FLAT WASHER 6MM 591 P4016591 RIVET 3 X 8
543 PW03M FLAT WASHER 6MM 592 P4016592 O-RING 20 X 2.4
544 PW03M FLAT WASHER 6MM 595 PK14M KEY 5 X 5 X 18
550 P4016550 OIL SIGHT COLLAR 596 P4016596 STEEL BALL 5MM
551 P4016551 OIL SIGHT COLLAR 597 PW04M FLAT WASHER 10MM
552 P4016552 OIL SIGHT GLASS 598 P4016598 PLUG M10-1.5 X 1
