3.
4.
Figure
13
Note: The left spindle uses the arbor bolt with
left-hand threads, which tightens by rotating it
counterclockwise. The right spindle arbor bolt
has right-hand threads and tightens by rotat-
ing it clockwise.
Figure 13.
5.
Note: One end cap also has left-hand threads
and is mounted on the left side of the machine.
The other cap has right-hand threads for the
right side of the machine.
