OM-BPM-G
Gas Piping Assemblies Parts List
GAS PIPING ASSEMBLIES
KEY
QTY PART NO#
1 2 U BOLT 3/4 PIPE N87786
2 5 WASHER PLAIN 1/4 005472
3 5 NUT HEXAGON KEPS 1/4-20 WITH 012940
4 1 ELBOW 90 DEG 1/2 NPT 008747
5 1 NIPPLE 1/2 NPT X 11 005673
6 1 IGNITION MODULE PLATE ASSY-ELECTRONIC IGNITION 144777
6 1 IGNITION MODULE PLATE ASSY-STANDING PILOT 146510
7 1 SWIVEL JOINT 1/2 NPT (GAS) 076680
8 2 UNION ELBOW 141354
9 1 TEE 1/2 NPT 008772
10
1 NIPPLE 1/2 NPT X 3.5 009816
11 1 COUPLING FULL 1/2 NPT 005722
12
1 NIPPLE 1/2 NPT X 10 005558
13 1 REAR RADIATION HEAT SHIELD 146145
14
1 IGNITION MODULE COVER 146146
15
2 SCREW ROUND HEAD MACHINE 018384
16
1 NIPPLE 1/2 NPT X 12 005600
17
1 VALVE GAS MANUAL SHUTOFF 098458
18
1 CONNECTOR MALE 1/2 049429
19
1 FITTING COMPRESSION 90 004584
20
1 TUBE, IGNITION SUPPLY TUBE, 1/4 (NOT SHOWN) 146119
21
1 PILOT SUPPLY TUBE, 1/4 (NOT SHOWN) 146118
23
1 GROMMET 7/8" (NOT SHOWN) 007400
24
1 SPARK IGNITION MODULE-ELECTRONIC IGNITION ONLY 144150
25
1 GAS CONTROL VALVE-ELECTRONIC IGNITION-NATURAL GAS 098443
25
1 GAS CONTROL VALVE-ELECTRONIC IGNITION-PROPANE 098444
25
1 GAS CONTROL VALVE-STANDING PILOT-NATURAL GAS 002648
25 1 GAS CONTROL VALVE-STANDING PILOT-PROPANE 002649
26
1 HIGH LIMIT THERMOSTAT (GAS) 013481
27
1 ELBOW FEMALE 90 DEG (NOT SHOWN) 050500
21 1 1 PILOT SUPPLY TUBE, 1/4" (STANDING PILOT) - (NOT SHOWN) 149054
