Grohe Avensys User Manual

5
Index
Spare Parts
T
able Of Contents . . . . . . . . . . . . . . . . . 1
I
nstallation Dimensions . . . . . . . . . . . . 2
S
pare Parts Drawing. . . . . . . . . . . . 3 + 4
S
pare Parts List. . . . . . . . . . . . . . . . . . . 5
T
echnical Data. . . . . . . . . . . . . . . . . . . . 6
I
nstallation . . . . . . . . . . . . . . . . . . . . . . . 7
Exposed Installation. . . . . . . . . . . . . . . 7
Shower Connection . . . . . . . . . . . . . . . 9
Adjustment. . . . . . . . . . . . . . . . . . . . . 10
M
aintenance . . . . . . . . . . . . . . . . . . . . 11
C
are . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
T
rouble Shooting . . . . . . . . . . . . . . . . 13
G
uarantee . . . . . . . . . . . . . . . . . . . . . . 15
Dear Customer,
Thank you for choosing a GROHE product.
Please follow these instructions carefully
and you will enjoy many years of reliable
service from this fitting.
No. Description Cat.-No.
Pack-
ing
unit
8 Set screw M5x12 02 125 5
9 Connection elbow 12 111 2
9.1 Flow limiter set 46 428 1
9.2 Non-return valve 06 544 2
9.3 O-ring seal 01 287 10
9.4 Filter 06 768 5
9.5 Escutcheon 00 197 2
No. Description Cat.-No.
Pack-
ing
unit
1 Lever complete 47 599 1
1.1 Cap 00 090 1
2 Cover Ring 00 565 1
3 Stop ring 47 593 1
4 Control unit 47 598 1
5 Wax element 00 798 1
6 Slider 07 587 1
7 Seat with spring 47 594 1
7.1 O-ring seal 03 169 5
956212.book Seite 5 Mittwoch, 19. Dezember 2001 8:04 08

Grohe Avensys Specifications

General

Category	Shower System
Exposed or Concealed	Exposed
Thermostatic	Yes
Hand Shower	Yes
Diverter	Yes
Finish	Chrome
Installation Type	Wall Mounted
Material	Brass
Warranty	5 years
Shower Head	Yes
