Technical Data
F
unctioning Principle
T
his Avensys mixing valve is a thermostatic
m
ixer with wax cartridge. Turning the shut-
o
ff lever in a counter-clockwise direction
o
pens the water flow. Turning the tem-
p
erature cross handle in a counter-clockwise
d
irection sets the temperature from cold to
h
ot.
T
his product is supplied with connectors to fit
ø
15mm pipework. Connection should be hot
l
eft, cold right as viewed from the operating
p
osition. The product is preassembled.
P
lumbing Systems
T
his thermostatic mixing valve is suitable for
i
nstallation with:
x Gravity-fed plumbing systems with an
open vented hot water cylinder
x Cold water storage cistern
x Mains pressure unvented and instantan-
eous thermal hot water storage systems
x Multi-point gas water heaters
x Combination boilers with a modulating hot
water output
S
upply Pipework
E
nsure the supply pipework is thoroughly
f
lushed before installing the mixing valve.
G
ROHE recommends installing isolating
v
alves upstream of the mixing valve for
s
ervicing purposes.
N
ew Water Regulations
T
his GROHE-product should be installed to
c
omply with the New Water Regulations
c
overing backflow prevention. It must also
b
e installed in accordance with local bye-law
r
equirements.
Specification
x Exposed thermostatic shower mixing
valve, concealed or exposed supplies
x Flow pressure
- Low pressure 0.1 - 1 ba
r
- High pressure 1 - 10 ba
r
x Avoid major pressure differences betwee
n
hot and cold water supply:
For different supply pressures use
enclosed flow limiters, see chapter
“Exposed Installation” on page 7.
x Max. operating pressure 10 ba
r
x Max. test pressure 16 ba
r
x Mixed water flow rate without downstream
resistance:
x Temperature
- Max. (hot water inlet) 80 q
C
- Recommended (for economy) 60 q
C
- Maximum temperature is reached when
the temperature cross handle is rotated
270q in a counter-clockwise direction.
x Water connection cold - R
H
hot - L
H
Pressure 0.1 0.2 0.3 0.4 0.5 0.6 bar
Flow rate 5 7.2 9.2 10.6 11.9 13.0 l/min
