Growatt MAX 175KTL3-X HV User Manual

2.2 Symbol Conventions
Symbol
Description
Indicates an imminently hazardous situation which,if not
avoided,will result in serious injury or death.
Indicates potentially hazardous situation which,if not avoided,will
result in serious injury or death.
Indicates potentially hazardous situation which,if not avoided,will
result in minor or moderate injury.
Indicates certain hazardous situation which,if not avoided,will rusult
in property damage.
Reminds operator to read installation manual before operating or
installing inverter.
2.3 Safety symbol description
Symbol
Name
Meaning
High Voltage
Electric Shock
Inverter operating with high voltage, any
operation regarding inverter need to be done by
trained and authorized electrical technician.
Burn Warning
Do not touch a running inverter cause it
generates high temperature on the case.
Protective
Grounding
Connect inverter to grounding bar.
Delay discharge
Residual voltage exists after the inverter is
powered off, it takes 5 minutes for the inverter
to discharge to the safe voltage.
Read the
installation
manual
Reminds operator to read installation manual
before operating or installing inverter.
DC
Means this terminal is for DC side
AC
Means this terminal is for AC side
CE Mark
The inverter complies with the requirements of
the applicable CE guidelines.
4
3
Other：
•After you receiving the inverter please check the packing materials for
damage,if there is any damage please contact your supplier.
•The Max PV input voltage should not exceed 1500V.
•For the disposed inverter,the consumer should dispose it according to
local disposal rules for electrical equipment waste.
CAUTION
NOTICE
WARNING
WARNING
DANGER
Information
