Growatt MOD 6000TL3-X Manual

AC connection steps(just for Vietnam models):
I. Pass the 5 wires (A,B,C,N and PE wires) through the AC shield
f
connect them to the
power grid, and then crimp the O/U terminal.
Fig 6.5
2. Lock the AC cable to the corresponding AC terminal.
Fig 6.6
3. Lock the protective cover on the inverter frame, and finally tighten the protective cover hole.
Fig 6.7
19

Growatt MOD 6000TL3-X Specifications

General

Brand	Growatt
Model	MOD 6000TL3-X
Category	Inverter
Language	English
