Growatt MOD 6000TL3-X Manual

Connect DC terminal
Cables
Positive metal terminal
Positive connector
4~6mm
2
4~6mm
2
Cables
Negative metal terminal
Fig 6.9
Negative connector
6.4 Connect the signal cable
The MOD series inverter has an16-Pin or 8-Pin signal connector except Vietnam models.The
client signal line port is as follows:
Fig 6.10
1.Strip the cable 10mm through the waterproof gland, thread sleeve, and tighten the
screws.
Bjust for Vietnam models
Fig 6.11
22
C just for Vietnam models
