OLED display and touch button 9
The OLED display can display the running status of the inverter, as well as various parame-
ters information, and the display interface of the inverter can be switched and the inverter
parameters can be set by touching the button.
9.1 Boot display
When the inverter is turned on, the OLED display interface is as follows:
9.2 OLED display wake up
After the inverter works normally for 5 minutes,the OLED display will be automatically
turned off.At this time,there is no display on the OLED,and the leaf of the indicator win-
dow is green.You need to view the dispaly data or make settings to make the OLED dis-
paly again through touch operation.
Switch the display interface or
the current number plus 1
Enter the setting state or
confirm
Return to the previous display
interface
The current data returns to the
default value
