Revision A9 15
GRT Avionics Mini-X Installation, Setup & User Manual
Section 2: Wiring Considerations
2.1 Mini-X Connector Definition
The Mini-X comes with a female DB15 connector pre-wired with the most commonly used wires.
The optional remote magnetometer uses a DB9 connector and is connected to the Mini using the
pins defined below. The colors shown here correspond to the colors in the supplied wiring harness.
� The supplied wiring harness for the magnetometer is 20 feet long; all other wires are 4 feet long.
� The magnetometer serial output (Mag pin 9) may be shared with other GRT Avionics Mini-EFIS,
or the GADAHRS.
� The magnetometer, OAT, serial ports and Trig TT22 connections are all optional.
� OAT is required for true airspeed and density altitude calculations when the Mini does not have
a serial connection to a working GRT Horizon or Sport EFIS display unit.
� Use Trig TT22 A and B connections for control and encoder information for the TT22.
� Any of the serial port pairs can be used for a variety of connections, including connection to
another GRT display unit for limited data sharing, serial transponder or handheld GPS.
Magnetometer DB9
Pin No.
Use Color
1 Serial 2 Out YEL
2 Serial 2 In YEL/WHT
3 Trig TT22 A
4 Trig TT22 B
5 Serial 1 Out GRN
6 Serial 1 In WHT/GRN
7 Ground BLK
8 Power in: 8-30V RED
8 (serial in) 9 Mag A/Serial 3 Out ORG
9 (serial out) 10 Mag B/Serial 3 In
ORG/BLK or
WHT/BRN*
5 (mag power - must be
powered by Mini-X or an adaptive
AHRS)
11 Mag C BLU or WHT/RED*
1 (ground) 12 Mag D WHT/BLU or BLK*
13 Audio Output
14 Audio Ground
15 OAT GRY
*Two possible wire colors sets are possible. Pin 8, serial input, is optional,
an can only be connected to one Mini.
