Operation
41 | 64
BA_712940
-inter_175_GENO
-Multi Nive
au.docx
7.2.3 Parameters
Settings in the programming level must be done by Grünbeck's
technical service or by a qualified specialist trained by Grünbeck
only.
In the tables below, the factory settings are greyed out. The factory
settings are preset for basic pure water tank GT 1000.
Index
Parameters
Setting range
Remarks
1
Measuring range
of probe
bar
0.10...0.25...9.99
Change only if a probe
other than 2.5 mWC is
used
2
Filling height
cm
1...164...999
Dimension C
3
Filling volume
0.01...0.84...9.99
4
Filling level
Alarm contact OFF
%
0...10...99
Switch-on/switch-off
point of alarm contact
5
Filling level
Alarm contact ON
%
0...20...99
6
Filling level of level a
%
1...80...99
Programmable contact
opens at a filling level of
80 %
7
Filling level of level b
%
1...60...99
Programmable contact
opens at a filling level of
60 %
8
Filling level of level c
%
1...40...99
Programmable contact
opens at a filling level of
40 %
9
Filling level of level d
%
1...20...99
Programmable contact
opens at a filling level of
20 %
A
Hysteresis of level
a c
%
1...5...99
Example
(acc. to factory setting):
Contact a closes
when the filling level
falls below 75 %
Contact b closes
when the filling level
falls below 55%
Contact c closes
when the filling level
falls below 35 %
