Grunbeck GENO-Multi Niveau User Manual

Operation
42 | 64
BA_712940
-inter_175_GENO
-Multi Niveau.docx
Index
Parameters
Setting range
Remarks
b
Hysteresis of level d
%
1...5...99
Contact d closes
when the filling level
falls below 15 %
c
Solenoid valve
OPEN
%
1...40...99
Make-up feed of tank
via solenoid valve
d
Solenoid valve
CLOSED
%
1...60...99
7.2.3.1 Examples for display and switching behaviour
Designation
Alarm contact
4 = 40 (ON) – enabled
5 = 60 (OFF) – disabled
Designation
Programmable contact level c
8 = 40 (OFF) – disabled
A = 8 (ON) – enabled
A
Hysteresis of level
Designation
1
Filling level in %
2
Time
► Program the switching points of the programmable contacts
and of the alarm contact in a way that no flutter switching
occurs.
