7.2.3.2 Programming of switching contacts a – d and configuration of
Alarm LED
For each programmable switching contact of level a – d, the assign-
ment normally open/normally closed can be made.
Normally, the Alarm LED lights up when the value of the parameter
programming is undershot (Index 4).
Index
Parameters
Setting
range
Remarks
1
Programmable contacts
Filling level of level a
0/1
0 = Normally closed contact
1 = Normally open contact
2
Filling level of level b
0/1
0 = Normally closed contact
1 = Normally open contact
3
Filling level of level c
0/1
0 = Normally closed contact
1 = Normally open contact
4
Filling level of level d
0/1
0 = Normally closed contact
1 = Normally open contact
5
Function of Alarm LED
0/1
0 = Normally closed contact
(LED lights up)
1 = Normally open contact
(LED does not light up if
alarm contact is OFF)
All contacts are factory-set as normally closed contacts.
► Reprogram the contacts in Code level 113, if necessary.
1. Simultaneously press and hold keys and for > 1 sec.
» The display changes to code request C 000.
2. Set Code C 113 using or .
3. Confirm with .
4. Select the desired parameter.
5. Set the desired value.
