13. Technical data and installation dimensions
13.1 Technical data
To avoid condensation in the control box and stator, the liquid
temperature must always be higher than the ambient
temperature.
Supply voltage 1 x 230 V - 10 %/+ 10 %, 50/60 Hz, PE.
Motor protection The pump requires no external motor protection.
Enclosure class IP42.
Insulation class F.
Relative air humidity Maximum 95 %.
System pressure Maximum 1.0 MPa, 10 bar, 102 m head.
Inlet pressure
Liquid temperature Minimum inlet pressure
≤ +75 °C 0.05 bar, 0.005 MPa, 0.5 m head
+90 °C 0.28 bar, 0.028 MPa, 2.8 m head
+110 °C 1.08 bar, 0.108 MPa, 10.8 m head
EMC EN 55014-1:2006 and EN 55014-2:1997.
Sound pressure level The sound pressure level of the pump is lower than 43 dB(A).
Ambient temperature 0 to +40 °C.
Temperature class TF110 to CEN 335-2-51.
Surface temperature The maximum surface temperature will not exceed +125 °C.
Liquid temperature +2 to +110 °C.
Ambient
temperature
[°C]
Liquid temperature
Min.
[°C]
Max.
[°C]
02110
10 10 110
20 20 110
30 30 110
35 35 90
40 40 70

Grundfos alpha2 l Specifications

General

Pump Type	Circulator Pump
Series	ALPHA2 L
Max Head	6 m
Voltage	230 V
Frequency	50/60 Hz
Temperature Range	2°C to 110°C
Material	Cast iron
Max Operating Pressure	10 bar
Installation Length	180 mm
Enclosure Class	IP42
Insulation Class	F
Weight	2.1 kg
Protection Class	Class I
