4. Preparing for installation
Before setting up your installation on GRM, make
sure that you have completed the following steps:
1. Write down the MAC address of the CIM 500.
Note: You can find the MAC address on a sticker
on the CIM 500 (the address with the lowest last
digit). You can also find it on the package in
which your CIM/CIU 500 was delivered in. You
will need this address when setting your
installation in GRM.
2. Select the GRM IP protocol on the CIM 500: set
the rotary switch to position 4.
3. Connect the CIM 500 to your GENIbus network.
4. Connect sensors and other equipment to the I/O
module of the CIU 50X (optional).
5. Connect the CIM 500 to your internet network.
If you are using a 3G/4G router, insert a SIM card
in the router and connect the router to the CIM
500 via an Ethernet cable.
6. Connect and switch on the power supply.
7. Check that the LED to the left on the CIM/CIU
500 change to permanently green, which
indicates that a connection to GRM is
established. This will take a couple of minutes.
You are now ready to register the CIM 500 on the
GRM server and to set up the application you want to
have monitored by the GRM system.
