Grundfos DMX 24-8 User Manual

7
V6.0
DMX model 226 en
Pump range DME...
Maximum pressure [bar]
Example: DME 2-18 A-PP/E/C-F-3 1 1E F
Control variant Code
Standard A
Standard + alarm relay AR
Standard + ProfIbus AP
Standard + GENIbus AG
Dosing head material Code
Polypropylene PP
PVDF PV
Stainless steel 1.4401 SS
Gasket material Code
EPDM E
FKM V
Valve ball material Code
Ceramics C
Stainless steel 1.4401 SS
Control panel Code
Front-fitted F
Side-fitted S
Voltage Code
1 x 100-240 V, 50-60 Hz 3
Code Mains plug
F EU (Schuko)
B USA, CAN
GUK
IAU
ECH
JJP
Code Connection,
suction/ discharge
1 Tubing 6/9
Tubing 4/6
supplied with the pump
2 Tubing 6/9
Tubing 6/12+9/12
supplied with the pum
3 Tubing 4/6
4 Tubing 6/9
5 Tubing 6/12
6 Tubing 9/12
A Threaded Rp 1/4
B Threaded Rp 3/8
E Cementing d.10
F Cementing d.12
Code Valves
1 Standard valve
2 Spring- loaded valve
Type key
(Cannot be used for pump configuration.)
