Grundfos GI SPC Series User Manual

26
English (GB)
P15.34
Threshold
setting for
switching to PV
input
P15.33–400V
If PV voltage is higher than the threshold, after the delay time of P15.24, it can
be switched to PV input through relay output. In order to avoid repeated
switching, the threshold needs to be higher than the threshold of P15.33.
If the value is 0.0, the function is disabled.
The default value depends on model.
For models of 220V:
0.75kW: 100.0V
1.5kW, 2.2kW and 4kW: 120.0V
For models of 380V:
2.2kW–5.5kW: 240.0V
Depend
on model
○
P15.35
Rated pump flow
The pump flow is QN if the pump runs at the rated pump frequency and rated
lift. Unit: cubic meter/hour.
0.0
○
P15.36
Rated pump lift
The pump lift is HN if the pump runs at the rated frequency and rated
current. Unit: meter
0.0
○
P15.37
Voltage setting
at PV
undervoltage
point
When the PV voltage is less than the preset voltage, the system reports the PV
undervoltage (UV) fault.
The default value depends on the model.
Setting range: 0.0–400.0
Depend
on model
○
P17 Group: Monitoring
P17.38
Current of the
main winding
Current of the main winding when applying the capacitance-removed mode to
control the 1PH motor
0.00–100.00A
0.00A
●
P17.39
Current of the
secondary
winding
Current of the secondary winding when applying the capacitance-removed
mode to control the 1PH motor.
0.00–100.00A
0.00A
●
P18 Group: Parameters of Monitoring controller state
P18.00
PV reference
voltage
MPPT is set at the controller side. This value is specified at the controller side.
●
P18.01
Current PV
voltage
It is the PV input voltage provided by the boost module.
●
P18.02
Bus voltage
reference
It is used to set the reference voltage of the bus when PV input is adopted.
For models of 220V, the default value is 330.0V.
and for models of 380V, the default value is 570.0V.
Setting range: 220.0V–600.0V
Depend
on model
●
P18.07
PV input power
Reserved. Unit: W
●
P18.10
Device
configuration
display
0: PV power supply
1: AC grid power supply
●
P18.11
Current flow of
pump
Q=Q
N
* f / f
N
, unit: m
3
/h
0.0
●
P18.12
Current lift of
pump
H= 0.9H
N
*( f/ f
N
)
2
, unit: m
0.0
●
P18.13
MSB of pump
total flow
Displaying the most significant 16 bits of the total flow of the pump. Unit: m
3
0
●
P18.14
LSB of pump
total flow
Displaying the least significant 16 bits of the total flow of the pump. Unit: m
3
Total flow of pump = P18.13 x 65535 + P18.14
0.0
●
