Grundfos MGE-F User Manual

4 / 32
1. Identification
1.1 Nameplates
The MGE-F nameplate (fig. 1) is fitted on the side of the terminal box (fig. 2).
The motor nameplates (fig. 3) are fitted under the terminal box (fig. 4).
TM04 2002 1808 TM04 2399 2508
Fig. 1 Nameplate for MGE-F, efficiency 1 motor Fig. 2 Position of nameplate
Pos. Description Pos. Description
1 Type designation 12 Max. supply current at min. and max. supply voltage
2 Product number 13 Supply voltage
3 Power factor 14 Rated power
4 Production code, year/week 15 Output frequency
5 Serial number 16 Output voltage
6 Weight 17 CE mark
7 Enclosure class according to IEC 34-5 18 VDE mark
8 Maximum ambient temperature 19 Standard motor efficiency according to CEMEP
9 Motor protection according to IEC 34-11 20 C-Tick mark
10 Insulation class according to IEC 62114 21 Country of manufacture
11 Frequency 22 Bar code
TM04 3051 3508
Fig. 3 Nameplates for standard motors with CE and UL approvals
TM04 2843 3208
Fig. 4 Position of motor nameplates
96
3
4
8
8
3
1
Type
Env.Type : 3R
P.N.
Serial No :
P.C.
PF :
U
in
I
in 1 /1
f in
OUTPUT
U
out
P
2
f out
Wgt
V
kW
V
A
Hz
:
0 -
:
kg
3 ~
:
Made in Hungary
INPUT
:
:
Hz
:
:
:
:
:
CL
TP 211
T
Amb
IP
:
C
:
:
0 -
12 3 45 6 7 8 910
11 12 13 14 15 16 17 19 20 21
22
18
MG180MB2-48FF300-F1
22,0
85903419
D/Y
380-415/660-690
41,5-38,5/23,8-22,8
91,9-92,8
45,5-42,5/26,0-25,0
0,91-0,89
2930-2940
D/Y
380-480/660-690
42,0-33,5/24,2-22,8
46,0-37,0/26,6-25,0
3500-3550
90,0-92,5
0,92-0,89
MG180MB2-48FF300-F1
4000
85903419
1000
40
60
UNIREX N3 ESSO
6310.C4
7310BE
15
Protector type PTC 160°C TP211
114
55
F
0931
