Grundfos SP Series User Manual

10.4.4 460 V, 3-phase, 60 Hz
Maximum submersible power cable length (maximum cable length in feet, starter to motor)
Motor
rating
[Hp]
AWG copper wire size
[ft (m)]
14 12 10 8 6 4 3 2 1 0 00 000 0000
460 V
3-ph
60 Hz
0.5
3770
(1149)
6020
(1835)
9460
(2883)
- - - - - - - - - -
0.75
2730
(832)
4350
(1326)
6850
(2088)
- - - - - - - - - -
1
2300
(701)
3670
(1119)
5770
(1759)
9070
(2765)
- - - - - - - - -
1.5
1700
(518)
2710
(826)
4270
(1301)
6730
(2051)
- - - - - - - - -
2
1300
(396)
2070
(631)
3270
(997)
5150
(1570)
8050
(2454)
- - - - - - - -
3
1000
(305)
1600
(488)
2520
(768)
3970
(1210)
6200
(1890)
- - - - - - - -
5
590
(180)
950
(290)
1500
(457)
2360
(719)
3700
(1128)
5750
(1753)
- - - - - - -
7.5
420
(128)
680
(207)
1070
(326)
1690
(515)
2640
(805)
4100
(1250)
5100
(1554)
6260
(1908)
7680
(2341)
- - - -
10
310
(94)
500
(152)
790
(241)
1250
(381)
1960
(597)
3050
(930)
3800
(1158)
4680
(1426)
5750
(1753)
7050
(2149)
- - -
15 -
340
*
(104
*
)
540
(165)
850
(259)
1340
(408)
2090
(637)
2600
(792)
3200
(975)
3930
(1198)
4810
(1466)
5900
(1798)
7110
(2167)
-
20 - -
410
(125)
650
(198)
1030
(314)
1610
(491)
2000
(610)
2470
(753)
3040
(927)
3730
(1137)
4580
(1396)
5530
(1686)
-
25 - -
330
*
(101
*
)
530
(162)
830
(253)
1300
(396)
1620
(494)
1990
(607)
2450
(747)
3010
(917)
3700
(1128)
4470
(1362)
5430
(1655)
30 - -
270*
*
(82
*
)
430
(131)
680
(207)
1070
(326)
1330
(405)
1640
(500)
2030
(619)
2490
(759)
3060
(933)
3700
(1128)
4500
(1372)
40 - - -
320
*
(98
*
)
500
*
(152
*
)
790
(241)
980
(299)
1210
(369)
1490
(454)
1830
(558)
2250
(686)
2710
(826)
3290
(1003)
50 - - - -
410
*
(125
*
)
640
(195)
800
(244)
980
(299)
1210
(369)
1480
(451)
1810
(552)
2190
(668)
2650
(808)
60 - - - - -
540
*
(165
*
)
670*
(204*)
830
(253)
1020
(311)
1250
(381)
1540
(469)
1850
(564)
2240
(683)
75 - - - - -
440
*
(134
*
)
550
*
(168
*
)
680
*
(207
*
)
840
(256)
1030
(314)
1260
(384)
1520
(463)
1850
(564)
100 - - - - - - -
500
*
(152
*
)
620
*
(189
*
)
760
*
(232
*
)
940
(287)
1130
(344)
1380
(421)
125 - - - - - - - - -
600*
*
(183
*
)
740
*
(226
*
)
890
*
(271
*
)
1000
(305)
150 - - - - - - - - - -
630
*
(192
*
)
760
*
(232
*
)
920
*
(280
*
)
175 - - - - - - - - - - -
670
*
(204
*
)
810
*
(247
*
)
200 - - - - - - - - - - -
590
*
(180
*
)
710
*
(216
*
)
*
Indicates single conductor only (not jacketed).
34
English (US)
