Grundfos UPMO Series - UPM3 - HYBRID Variants; Examples of Systems

UPM3 - HYBRID variants
This pump range with operating panel is designed for
several purposes:
• The internal-controlled variant can be used in heating
appliances as stand-alone or replacement pump, for
example in heating kits.
• The remote-controlled variant can be integrated in
boilers and other heating appliances where the speed
is changed, corresponding to low-voltage PWM signal
input.
• A combination of both.
The internal-controlled variants are suitable for the
following systems:
• Systems with constant or slightly variable flows such
as one-pipe heating systems
• Systems with variable flows such as two-pipe heating
systems with thermostatic valves for radiators or
underfloor heating.
Examples of systems
TM060528
One-pipe heating system
TM060526
Two-pipe heating system
TM060527
Underfloor heating system
UPM3
3
9
Applications
