GSI Group - Laser Division
JK300HP/JK300P/JK125P
Pre-installation and User Manual Issue 2.0
Page 154 of 172 Part No: 1EA300E01
9.16 Pointing Diode Replacement
Personnel authorised to Maintenance Level 2 can carry out this procedure.
9.16.1 Materials
Part Required Part Number
Pointing Diode Assembly PC120150X
Tools/Equipment Consumables
Standard Tool Kit
Door key
9.16.2 Replacement Procedure
4 (3 off)
3 (4 off)
5
1
2 (3 off)
Figure 32 – Pointing Diode
