27
Take off plug of electricity enrichment valve
Take off carburetor
Electricity Enrichment Valve
Inspection
Check connected line of electricity enrichment value.
Resistance value:
Stop the engine and after 10 minutes then test resistance. Value
should not higher than 10 omegas. If no connection or resistance
value is deviated 10 omegas, you must use a new electricity
enrichment valve.
Disassembly
Take down screws of support pats and take down support part.
Take down electricity enrichment valve.
Inspection of Valve
Check any damage on electricity enrichment valve and pin
of EEV. If any, please use a new EEV.
Installation
Do installation in oppositive turn in disassembly.
E.E.V.
Connecter
Screws of support part
Support part
E.E.V. Pin
E.E.V.
Attention!
Press EEV at bottom and fix its channel outside with support part.
