30
Take off main ejector, pin ejector socket, pin ejector, sub ejector and vent screws.
Clean ejector with extractive oil.
Clean carburetor pass way with huffing air.
Installation
Install pin ejector, pin ejector socket, main ejector, sub ejector and vent screws.
Install pin valve, floater and pin.
Install carburetor in oppositive turn in disassembly.
Do adjustment as following：
．Accelerator line adjustment
．Idle adjustment
Oil Tank
Disassembly
Main Ejector
Sub Ejector
Main Ejector
Socket
Vent bolt
Important!
. To protect ejector and screws
.Note down zip number when take down screws. If
drives vent-screws strongly, it would be destroyed.
Attention!
Extractive oil should be fresh one.
Attention!
Please install vent screws according to zip number noted down when
disassembly.
Vent bolt
Sub Ejector
Main Ejector
Socket
Main Ejector
Oil tank
