33
Temperature Control Switch
Disassembly
Drain radiator liquid out
Dismantles switch wiring.
Dismantles the switch
5 Engine
Disassembly
Dismantles Earth Line from the battery
Lift back vehicle with Left and Right support parts, and make sure rear
Wheel takes off;
Take down screws and take off rear wheel;
Take down screws and take off rear brake;
Take down rear bone [left and right], break connection between rear bone
and engine
Take off gimbals [left and right]
Take apart water line and out cooling liquid
Rear Wheel Screw
Support Part
Attention! When 80°C, the fan can automatically
open; if failed, it needs the prompt inspection.
Rear Brake
Rear Bone
To Next Page
