Specification
Item Standard Value
Battery
Capacity 14AH
Voltage （in full）
At least 12.5V
Charge current Standard 1.4A
Charge time Standard 13 hours
Rectifier of Voltage
Model Semiconductor switch type
Control voltage 14.0-15.0V
Resistance value of Charge Coil
（20℃）
0.1-1.0Ω
Troubleshooting
No Power(Ignition trigger is “OFF”) Voltage is lower
－The battery is at the electric discharge condition ．The battery charge is not good or at the electric
discharge condition
－Storage battery leakage ．Voltage Rectifier not to good
－Voltage Rectifier not good ．The magnetic stator not good
－The magnetic stator not good ．Coupling connection is not good
－Battery not good
．
Battery line cable connection falls off Electric current not steady-going on
．Fuse in short ．Line cable connection not good
．
Line cable in short ．Charge system not good
．
Ignition trigger not good ．Ignition system not good or in short
．C
oupling connection is not good or short
Charge system
Leakage examination
Put ignition switch to OFF, and take out positive or cathode electrode line of battery. Take out your
digital multitester and put switch to “mA” position, connect battery line and battery to examine its
leakage flow value. If value is bigger than 15mA that means that the entire vehicle has the leakage
problem, you should promptly arrange looks up.
Control voltage inspection
