GSMOON KD260-2 - Steering Assembly Disassembly; Steering System Removal Steps

39
Take apart U/D support part and front bone.
It is same to RIGHT WHEEL.
Take down three screws and take apart steering support nips.
Take down screws between steering assembly and gimbal.
Take apart steering assembly.
Take down screws between steering bearing and gimbal.
Take off gimbals.
Take down screws between steering bearing and vehicle body.
Take apart steering assembly.
Front Bone
U/D Support Part
Fix part of S.S.
Steering assembly
Bolt
Gimbal
Fixing parts of S.W.
Bolt
Gimbal
Screw
Steering assembly
Important! It is connected by wimble
please knock assembly carefully.
