44
Dismantles 2 setting screws, and take down the brake to pump.
Dismantle locking screws, take down the trailing wheel.
Dismantle two setting screws and take down brake pump.
Dismantle two setting screws and take down rear brake pump.
Dismantle four setting screws of rear bone
Take down rear bone, rear wheel rim and brake disc assembly.
Take down rear bone off rear wheel rim
Dismantle four setting screws and take off brake disc.
Take off SPEED SENSER ASS.
Parking Brake
Rear brake pump
Screw
Screw
Rear Bone
Brake Disc
Rear Wheel Rim
Screw
Important!
IT IS CONNECTED WITH AXLTREE;
YOU SHOULD USE PROFESIONAL TOOL.
Parts of speedometer
Parking Brake
Screw
