Standard Torque Rating
SER
NUM
Position
XYKD
Diameter of screw
（mm）
Torque（N.m）
1 Screw used between Exhaust pipe and Front Cylinder 8 20-26
2 Igniter plug 10 18-20
3 Screw used between Front wheel hub and front universal
joint
14 80-100
4 Screw used for Rear wheel hub and Constant-velocity joint 18 120-140
5 Universal joint fastening bolt 8 20-26
6 Bolt of protective parts of steering mechanism 8 30-40
7 Screws between handle ball and gimbal 10 50-60
8 Screws of wheel and wheel rim[Front and rear] 10 50-60
9 Screws of support parts[Front wheel] and vehicle body 10 50-60
10 Connection of brake pump parking brake and front gimbals,
elevation
8 20-26
11 Screws of handle adjusting line 10 30-40
12 Screws exhaust pipe and engine rear support part 8 20-26
13 Screw used on Front Vibration Damper 10 30-40
14 Screw used on Rear Vibration Damper 12 50-60
15 Connecting screws between rear support part and vehicle
body
16 110-130
16 Screws of rear support parts of engine 10 30-40
17 Screws of front support parts of engine 10 30-40
18 Screws of back brake disc and back wheel rim 8 30-40
19 Screws of front brake disc and front wheel rim 6 20-26
