GSW 110 - Specifications

3
SPECIFICATIONS
Model 110 310 510
Natural Gas Input
(Operating Range)
Min.: 19,500 BTU/h
Max.: 140,000 BTU/h
Min.: 11,000 BTU/h
Max.: 190,000 BTU/h
Min.: 11,000 BTU/h
Max.: 199,000 BTU/h
Propane Input
(Operating Range)
Min.: 19,500 BTU/h
Max.: 140,000 BTU/h
Min.: 11,000 BTU/h
Max.: 190,000 BTU/h
Min.: 11,000 BTU/h
Max.: 199,000 BTU/h
Gas Connection 3/4” NPT
Water Connections 3/4” NPT
Water Pressure 15 - 150 psi*
Inlet
Pressure
Natural Gas Min. 5.0” WC, Max. 10.5” WC
Propane Min. 8.0” WC, Max. 14.0” WC
Manifold
Pressure**
Natural Gas 2.0” WC 2.0” WC 2.0” WC
Propane 2.5” WC 3.7” WC 3.7” WC
Weight 13Kg (28.7 lbs.) 15.7Kg (34.6 lbs.)
Dimensions
520mm(H) x 351mm(W) x 170mm(D)
H20.5” x W13.8” x D6.7”
520mm(H) x 351mm(W) x D216mm(D)
H20.5” x W13.8” x D8.5”
Ignition Electric Ignition
Electric
Supply 120 VAC, 60 Hz
Consumption
Operation 73.1 W / 0.61 A 87.6 W / 0.73 A 89.8 W / 0.75 A
Standby 6.2 W / 0.05 A 6.2 W / 0.05 A 6.2 W / 0.05 A
Freeze-Protection 111 W / 0.93 A 111 W / 0.93 A 111 W / 0.93 A
* 40 psi or above is recommended for maximum flow.
** The Manifold Pressure is the factory setting and generally should not need adjustment.
NOTE:
• Check the rating plate to ensure this product matches your specifications.
• The manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice
and without incurring obligations.
