Gtech HT04 - Part Location and Unpacking

helpline 01905 345891 email support@greytechnology.co.uk web www.gtechonline.co.uk
7
Unpacking: Part Location
10
1
2
3
4
5
6
7
8
9
1 Main unit
2 Interlock switch
3 Rear on/off switch
4 Middle on/off switch
5 Front on/off switch
6 Telescopic tube latch
7 Head angle lock button
8 Blade release buttons
9 Visor Screw
10 Visor
11 Cutting Blade Guard
12 Cutting Blade
13 Battery Pack
14 Charging Stand
15 Battery Charging socket
16 Charging adaptor
17 Charging connector
18 Branch cutter attachment*
19 Grass shears attachment*
20 Weed basher attachment*
13
14
15
17
16
18 19 20
11
12
* * *
*Only included with some models. All attachment tools are available to purchase
separately from www.gtechonline.co.uk or 01905 345891.
