Unpacking: Part Location
1
2
5
3
8
9
4
11
7
6
12
Do not use in rain or leave outdoors whilst raining.
1 Main Unit
2 Brush Bar
3 Front Visor
4 Dust Tray
5 Edge Wheel
6 Upper Handle
7 Handle Tubes
8 Lower Handle*
9 Charging Adaptor*
10 Charging Jack
11 LED Indicator
12 ON/OFF button
helpline 01905 345891 email support@greytechnology.co.uk web www.gtechonline.co.uk
4
Technical specification
Unit operating cycle with full battery up to 60 minutes (dependent on floor surface)
Battery type 4.8V DC 1.3Ah
Charging period for fully discharged battery 16 hours
Battery charger output 10.0V DC, 150mA
Battery charger model KA23D100015033K
Sound level 75dB(A)
Weight 1.3Kg
WARNING: Only use a replacement battery as supplied by the manufacturer.
WARNING: Only use the charger provided with the product. Using another charger
may damage the product and battery.
*will be packed inside 4 Dust Tray
