TASK
MAINTENANCE OF THE LIFTER
EVALUATED MACHINE: TORO RANGES B, C & D
Identified Risk
Likelihood Severity Consequence
Corrective Measures
L M H SD D ED I To Mo H In
THE LIFTER IS DIRTY.
X X X
CLEAN IT AND GREASE THE
APPROPRIATE PARTS.
DAMAGED OR WORN
WINCH.
X X X
CONTACT THE
MANUFACTURER.
LEVELLERS BLOCKED.
X X X
GREASE LEVELLERS OR
CONTACT THE
MANUFACTURER.
STORAGE AREA IN BAD
CONDITION.
X X X
PROTECT THE LIFTER
CORRECTLY.
LACK OF AWARENESS OF
THE MAINTENANCE
REQUIRED FOR THE LIFTER.
X X X
CONSULT THE INSTRUCTION
MANUAL OR CONTACT THE
MANUFACTURER.
MISSING LABELS.
X X X
REPLACE LABELS.
LOSS OF MANUAL.
X X X
REPLACE INSTRUCTION
MANUAL OR CONTACT THE
MANUFACTURER.
CHANGE COMPONENTS.
X X X
ORDER ORIGINAL
REPLACEMENTS.
FULL REVISION AND
SERVICING OF THE LIFTER.
X X X
THIS MUST BE CARRIED OUT
BY A TECHNICIAN
AUTHORISED BY GUIL.
TASK
TRANSPORTATION OF THE LIFTER
EVALUATED MACHINE: TORO RANGES B, C & D
Identified Risk
Likelihood Severity Consequence
Corrective Measures
L M H SD D ED I To Mo H In
STABILISER LEGS NOT
SECURED.
X X X
BLOCK THEM WITH THE
LOCKING BOLTS.
UNFOLDED SIDE STABILISER
LEGS.
X X X
FOLD SIDE STABILISER LEGS.
MAST SECTIONS NOT FULLY
LOWERED.
X X X
LOWER THE MAST SECTIONS
AND SECURE THEM WITH THE
BLOCKING HOOK.
CABLE LOOSE.
X X X
WIND THE CABLE PROPERLY
ONTO THE WINCH DRUM.
DAMAGED WHEELS.
X X X
CHANGE WHEELS.
WINCH HANDLE STICKS
OUT.
X X X
POSITION THE TOWER TO
PREVENT DAMAGE TO THE
HANDLE.
LIFTER LOOSE IN THE
TRANSPORT VEHICLE.
X X X
SECURE THE LIFTER WITH
SLINGS OR ROPES.
THE LIFTER CANNOT BE
LOADED INTO THE VEHICLE.
X X X
USE SUITABLE LIFTING
TECHNIQUES.
