TASK
USING THE LIFTER
EVALUATED MACHINE: TORO RANGES B, C & D
Identified Risk
Likelihood Severity Consequence
Corrective Measures
L M H SD D ED I To Mo H In
LOAD INSUFFICIENTLY SECURED
TO THE LIFTER.
X X X
SECURE THE LOAD CORRECTLY.
UNEVEN WRAPPING OF THE
CABLE IN THE WINCH DRUM.
X X X
UNWIND THE CABLE AND WIND IT
EVENLY BACK ONTO THE DRUM.
THE LOAD SURPASSES THE
MAXIMUM PERMITTED LOAD
SPECIFIED BY THE
MANUFACTURER.
X X X
1.- DO NOT LIFT.
2.- REMOVE THE SURPLUS LOAD.
3.- CONSULT TECHNICAL
SPECIFICAITONS.
DISPLACED LOAD.
X X X
CENTER THE LOAD.
UNLEVELLED LIFTER AFTER
LOADING.
X X X
1.- DO NOT RAISE THE LOAD.
2.- LEVEL THE TOWER.
THE TELESCOPIC MASTS WON’T
RAISE.
X X X
1.- REMOVE THE PROFILE BLOCKING
HOOK.
2.- ENSURE THE CABLE IS SECURED TO
THE WINCH DRUM.
3.- CONSULT A GUIL TECHNICIAN.
DIFFICULTIES IN MOVING THE
LIFTER / NO LOAD.
X X X
1.- UNBLOCK THE BRAKES ON THE
WHEELS.
2.- CHECK THERE IS NOTHING
IMPEDING THE LIFTER BEING MOVED.
3.- CONSULT A GUIL TECHNICIAN.
DIFFICULTIES IN MOVING THE
LIFTER / WITH LOAD.
X X X
1.- UNLOCK THE BRAKES ON THE
WHEELS.
2.- CHECK THERE IS NOTHING
IMPEDING THE LIFTER BEING MOVED.
3.- CONSULT A GUIL TECHNICIAN.
THE MASTS START TO RAISE
CROOKED (NOT STRAIGHT).
X X X
1.- DO NOT MOVE OR RAISE.
2.- LOWER THE LOAD AND LEVEL THE
LIFTER.
3.- CONSULT A GUIL TECHNICIAN.
THE MAST PROFILES WON’T
LOWER.
X X X
1.- ENSURE THAT THE PENDULUM
BRAKE (IPB SYSTEM) IS NOT ENGAGED,
BLOCKING THE MAST PROFILES.
2.- ENSURE THE LIFTER IS NOT
OVERLOADED.
3.- CONSULT A GUIL TECHNICIAN.
CROOKED RAISING WHEN USING
TWO OR MORE LIFTERS
CONNECTED.
X X X
SYNCRONISE THE RAISING, IN SPEED
AND HEIGHT.
CROOKED LOWERING WHEN
USING TWO OR MORE LIFTERS
CONNECTED BY A LOAD.
X X X
SYNCRONISE THE LOWERING, IN
SPEED AND HEIGHT.
A NON-AUTHORISED PERSON
HAS TRIED TO USE THE LIFTER
WITH A RAISED LOAD.
X X X
1.- CORDON OFF THE WORK SPACE AS
A RESTRICTED AREA.
2.- REMOVE THE WINCH HANDLE.
IMMINENT FALLING OF THE
LIFTER.
X X X
EVACUATE PERSONNEL.
