Guldmann GH3 - Lifting Hanger Installation

10
© Guldmann GB/US-12/2018 • # 550383_9.00
© Guldmann GB/US-12/2018 • # 550383_9.00
Fig. 5
5. The GH3 Cross hanger is ready to use,
when it is able to move freely in a
horizontaI position (Fig. 6)
A
Fig. 6
Installation of GH3 Horizontal lifter
Use the oval hook to install the Horizontal
lifter. (Fig. 7 and 8)
Important:
Check that none of the lifting straps are
twisted after the installation of the GH3
Horizontal lifter
Fig. 7
Fig. 8
