Guldmann GH3 - Scale Module (GH3+ with Integrated Scale Module)

22
© Guldmann GB/US-12/2018 • # 550383_9.00
© Guldmann GB/US-12/2018 • # 550383_9.00
2.07 Scale module (GH3+ with integrated scale module)
The GH3+ with scale module (option) provides the facility to determine the
user’s weight.
Warning!
If the scale is required to comply with the Non-automatic weighing instru-
ments directive (EU Directive 2014/31/EU), a Class III scale must be used.
Setting the units, kg/lbs (Scale module)
Menu Start
Scale
KG
Show
Statistics
2008.04.22
Next service
Setup
Setup
Change
Scale
KG
1. Press any key on the hand control to activate the hoist.
When the lifting module is activated, the display on the hand control is
switched on and the Guldmann logo “G” appears.
2. Select “Menu” using the function key located below the display
3. Then select until the “Setup” menu appears in the display.
4. Select “Setup” and then until the “Units” menu appears in the display.
5. Select “Change” to switch between the units kg and lbs, and conrm the
selection by pressing “OK”.
6. Select to return to the start menu.
7. The display in the hand control switches off automatically after use
(approx. 8 min). (See the complete menu summary, section 2.04,
Supplementary modules, GH3)
