Guldmann GH3 - Class III Scale Specifications

29
© Guldmann GB/US-12/2018 • # 550383_9.00
© Guldmann GB/US-12/2018 • # 550383_9.00
Scale Info 1-2
Version
01.00
Next
Version (information screen 1 of 2 in scale menu):
• The number before the decimal counts the software versions and
larger modications
• The number after the decimal counts minor software modications
and bug xes
Scale Info 2-2
Changes
001
Next Exit
Changes (information screen 2 of 2 in scale menu): change counter
• Counts changes in software parameters such as calibration and
values for G factor
Error notications
- - -
Scale W2
Exit
The scale is overloaded.
Please follow the scale’s prescribed load (see identication label on
the hoist).
- - -
Scale W1
Reset Exit
The scale is below the minimum possible reading value
(in other words, the load weighed is under 2 kg).
Select ”Reset” and start over with setting the scale.
004
Scale
ExitReset
An error has occured in the scale. The display shows an error code
(see table below)
