Guldmann GH3 - Page 42

Label Item No.
Medical scale 558812_1
Material
Item No. 550187
Norris Print-Tech A/S
Transparant polyester
THERMLfilm PM 200 CLEAR
TC-387 L-23
Item No. 944406
Thermo transfor ribbon
NPT RZXXXUL
Black
Approvals acc. To
UL Standard 969
UL file: MH 27707
(CCN: PGJI2)
Size
75 x 50 mm
Font
Arial 2018.06.25
ECTYNO 0200-NAWI-03847
Event Counter: 1
ECTYNO 0200-NAWI-03847
Event Counter: 1
Rev. No Revision note Date Drawing by
1.1 Text changed 25.06.2018 APC/LE
Guldmann Scale Class
Guldmann Scale Class
e = kg Min kg Max kg
W1 xxx xxx xxx
W2 xxx xxx xxx
e = kg Min kg Max kg
W1 xxx xxx xxx
W2 xxx xxx xxx
M xx
M xx
0200
0200
Stroke 0,3 pt
Times New Roman Regular 7 pkt
Arial Regular 7 pkt
Arial Bold 12 pkt
picto_TemperatureLimitation_24x13
Arial Regular 12 pkt
picto_MedicalScaleClassIII_15x7
1
42
© Guldmann GB/US-12/2018 • # 550383_9.00
© Guldmann GB/US-12/2018 • # 550383_9.00
Examples of serial number label
Lifting module
Transformer Class 1
Lifting hanger Hand control
Type approval label,
lifting module with Class III scale
Part no. xxxxxx
Edition x xx
Prod. date yyyy-mm-dd
Serial no. xx x xx
max
xxx kg/xxx lbs
V. Guldmann A/S
www.guldmann.com
Barcode 128C
Part no. xxxxxx
Edition xxx
Date xxxx-xx-xx
IP44
max xxx kg / xxx lbs
xxxxxx
xxxxx
GH3+ xxx xxx xxxx
V. Guldmann A/S
Graham Bells Vej 21-23A
8200 Aarhus N, Denmark
Made in Denmark
yyyy-mm-dd
33V AC, 2.5A, IP20
Duty cycle 2 min ON/18 min OFF
GS1-128
V. Guldmann A/S
Graham Bells Vej 21-23A
8200 Aarhus N Denmark
Made in China
Type DK-13991
Input 100 - 115V AC 50-60 Hz, 1A
Input 230V AC 50-60 Hz, 0,5A
Input 220V AC 60 Hz, 0,5A
Output 33V AC 2,5A
IP20
year/week
Batch No.
