2A-27-60: Flaps System
1. General Description:
The aps system for the Gulfstream IV provides a means for the ight crew to
control the position and movement of the trailing edge aps, in order to allow
steeper approach and climb angles, and lower takeoff and landing speeds.
The aps are manually operated, electrically controlled, hydraulically powered,
mechanically actuated airfoils located on the inboard trailing edge of the left and
right wings. Designed as single-slotted Fowler-type aps, they ride on rollers
along four curved ap tracks attached to the rear beam of each wing.
Mechanical actuators (commonly referred to as screwjacks), driven by a hydraulic
motor through a central gearbox, extend and retract the aps. As the screwjacks
extend the aps, the aps move aft and downward to increase wing area and
camber.
An asymmetry protection system monitors ap position to prevent unequal
movement. If one ap moves further than the other, the protection system stops
ap movement by shutting off the hydraulic pressure source to the hydraulic
motor.
A FLAP handle, located on the center pedestal, controls normal ap extension
and retraction to four positions. Emergency ap control is provided by an EMER
FLAP handle located on the copilot’s right console. Flap position is displayed on
the FLAP / STAB position indicator located on the copilot’s skirt panel.
Extending the aps normally results in a nose pitch down movement as the aps
increase wing lift. To compensate for nose pitch down, the horizontal stabilizer
leading edge moves down corresponding to ap extension. Horizontal stabilizer
operation is described in Section 2A-27-50, Horizontal Stabilizer System.
Units and components in the aps system receive electrical power from the
Essential DC bus. The primary source of hydraulic power for the system is the
Combined hydraulic system, with the Utility hydraulic system available as a
backup source. If both the Combined and Utility hydraulic systems are not
available, the Auxiliary hydraulic system can be used to position the aps using
the AUX pump.
The ap system is composed of the following subsystems, units and components:
Flap handles
Flap shutoff valve
Flap selector valve
Hydraulic motor and central gearbox
Flap actuators
Flap follow-up switches
Flap asymmetry protection system
Flap position indication system
Aircraft conguration warning system
Flap control circuit breakers
A description of ap operation is also provided in this section.
2. Description of Subsystems, Units and Components:
(See Figure 17 through Figure 20.)
