J. Flap Control Circuit Breakers:
The FLAP CONT circuit breaker incorporates a switch which closes if the
breaker opens (manually pulled or popped). Power through the closed
MANUAL FLAP CONT circuit breaker and asymmetry switches will then
energize the ap control relay. The ap control relay, in turn, energizes the
ap shutoff valve open and hydraulic pressure ows to the ap selector
valve. In this conguration, the EMER FLAP handle can be used to select
ap position. If the MANUAL FLAP CONT circuit breaker opens (manually
pulled or popped), both normal and emergency operation of the aps is
inhibited.
K. Flap Operational Description:
(1) Normal Operation:
Moving the FLAP handle from one detent to another actuates one of
the four handle switches associated with the selected ap position.
The switch closes and power is routed through a follow-up switch
associated with the desired ap position and direction (e.g., down to
10°)totheap control relay through ap asymmetry switches.
If the aps are symmetrical, the ap control relay energizes. The ap
shutoff relay energizes to the open position and the ap selector
valve shifts to the extend or retract position. Combined, Utility or
Auxiliary hydraulic system pressure then ows through the open
shutoff valve to the selector valve, which directs pressure through
ow regulators to the appropriate side of the hydraulic motor.
As the hydraulic motor turns, it drives the aps in the desired
direction through the central gearbox, torque shafts and screwjacks.
The central gearbox at the same time also drives the horizontal
stabilizer to the desired setting to maintain longitudinal stability.
When the aps reach the desired position, the follow-up switch
opens, breaking the circuit to the ap control relay. The relay
de-energizes to close the ap shutoff valve and the ap selector
valve is de-energized closed. Hydraulic pressure stops and the aps
stop moving.
(2) Emergency Operation:
Placing the EMERG FLAP switch to EMERG deactivates the normal
FLAP handle and follow-up switches to allow direct control of the
ap control relay. A red X appears on both the pilot’s and copilot’s
normalized AOA display (lower left portion of the Primary Flight
Display [PFD]). The ap control relay energizes to open the ap
shutoff valve and hydraulic pressure ows to the ap selector valve.
Flap asymmetry protection is still provided because ap control
relay power is routed through the asymmetry switches.
Moving the EMER FLAP handle from NEUTRAL to the FLAPS UP
or FLAPS DOWN position directs hydraulic pressure through the
ap selector valve to the hydraulic motor. The motor operates and
the aps move. When the aps reach the desired position, moving
the EMER FLAP handle to NEUTRAL stops the aps.
3. Controls and Indications:
(See Figure 17.)
OPERATING MANUAL
PRODUCTION AIRCRAFT SYSTEMS 2A-27-00
Page 59
January 31/02
Revision 6
